Durable Injection Plastic Mould Runner Cleaner , Mould Cleaning Machine
| Place of Origin: | ZHEJIANG,CHINA |
| Brand Name: | KASSEL |
| Certification: | CE,ISO |
| Model Number: | KMX |
| Minimum Order Quantity: | ONE |
| Price: | N.A. |
| Packaging Details: | Export Wooden Case |
| Delivery Time: | N.A. |
| Payment Terms: | T/T |
| Supply Ability: | 15 SETS PER MONTH |
|
Detail Information |
|||
Product Description
316 Stainless Steel Model Cleaner For Die Casting And Inject Model
Quick Detail:
Model cleaner are designed to clean the model that cannot clean easily by hand. The model will be have some carbon in the pipe when the machine working long time. The model cleaner can raise heat efficiency and energy save.
Description:
All stainless steel structure composed of senior SUS316L stainless steel seal welding, acid and alkali resistant, attractive and durable. Ultrasonic oscillator (ultrasonic transducer) and ultrasonic vibration box well suitable patent ultrasonic vibrator is used to connect the bonding process, the ultrasonic vibrator high transmission efficiency, long service life, the fission type structure, the vibration plate and between the ultrasonic generator using high frequency connection socket, use and maintenance are convenient. Flexible installation, according to the need of ultrasonic radiation surface can be not only in the bottom, side or top of the cleaning trough
Specifications:
|
Model |
KMX-30 |
||
|
Medium |
Special cleaner or water |
||
|
Size of in&outlet |
3/8"(10A)*4 |
||
|
Tank |
30L |
||
|
Temperature |
≤50℃ |
||
|
Total Power (KW) |
6 |
||
|
Water pump |
power(KW) |
1.5 |
|
|
Flow (L/min) |
33 |
||
|
Pressure (KG/CM3) |
8 |
||
|
Pipe |
outlet(inch) |
3/8"(10A)*4 |
|
|
inlet(inch) |
3/8"(10A)*4 |
||
|
Leakage (inch) |
1/2"(15A) |
||
|
Cooling water (inch) |
3/8"(10A) |
||
|
Pressure air(mm) |
φ12 |
||
|
Power |
380V,50Hz |
||
|
Pressure air |
(Kg/cm2) |
≥6～8 |
|
|
Size |
L(mm) |
1250 |
|
|
W(mm) |
500 |
||
|
H(mm) |
1200 |
||
|
Weight (kg) |
85 |
||
Competitive Advantage:
Easy to use and portable, model can be cleaned without disassembling, convenient mould maintenance
A number of alarm protections to protect the machine stable operation.
There will be no water at function of automatic clean
Mould thermal conductivity stability and easy management after cleaning
It is convenient to clear die-casting, injecting and others runner model
Cleaning formula:
● Formula: Independent research and development of environmentally friendly waterway cleaning powder, the application of molecular stripping effect, through the water scale will scale away from the independent formula to ensure no corrosion, cleaning formula on the mold material, seals, plastic pipe, brass, stainless steel, No harm, and in line with national emission standards, can effectively loosen the scale and rust of the cooling water.
Compressed air:
● Principle Overview: Water flow through the positive and negative direction switch, water vapor integration, the very tiny bubbles in the same point instantaneous superimposed with tens of Mpa pressure. Micro-bubbles can penetrate the scale wall, rust wall, it will be loose and washed out. Impact bursting tube wall attachments and corrosion, high-speed water to take away the pipe was washed out of the dirt.
