Product Details
Place of Origin: CHINA
Brand Name: KASSEL
Certification: CE
Model Number: KMX
Payment & Shipping Terms
Minimum Order Quantity: ONE
Price: N.A.
Packaging Details: EXPORT WOODEN PACKING
Delivery Time: N.A.
Payment Terms: TT LC
Supply Ability: 15 SETS PER MONTH
Pipe Cleaner For Mould Runner Cleaner And Inject Machine Clear
Quick Detail:
The model cleaner can raise heat efficiency and energy save.Model cleaner are designed to clean the model that cannot clean easily by hand. The model will be have some carbon in the pipe when the machine working long time.
Description:
Ultrasonic oscillator (ultrasonic transducer) and ultrasonic vibration box well suitable patent ultrasonic vibrator is used to connect the bonding process, the ultrasonic vibrator high transmission efficiency, long service life, the fission type structure, the vibration plate and between the ultrasonic generator using high frequency connection socket, use and maintenance are convenient. Flexible installation, according to the need of ultrasonic radiation surface can be not only in the bottom, side or top of the cleaning troughAll stainless steel structure composed of senior SUS316L stainless steel seal welding, acid and alkali resistant, attractive and durable.
Specifications:
|
Model |
KMX-90 |
||
|
Medium |
|
||
|
Size of in&outlet |
3/8"(10A)*6+1-1/2"(40A)*1 |
||
|
Tank |
90L |
||
|
Temperature |
|
||
|
Total Power (KW) |
12 |
||
|
Water pump |
power(KW) |
3.0 |
|
|
Flow (L/min) |
133 |
||
|
Pressure (KG/CM3) |
8 |
||
|
Safe protection |
|
||
|
Others function |
mute, reset |
||
|
Pipe |
outlet(inch) |
3/8"(10A)*6+1-1/2"(40A)*1 |
|
|
inlet(inch) |
3/8"(10A)*6+1-1/2"(40A)*1 |
||
|
Leakage (inch) |
1/2"(15A) |
||
|
Cooling water (inch) |
|
||
|
Pressure air(mm) |
φ12 |
||
|
Power |
|
||
|
Pressure air |
(Kg/cm2) |
|
|
|
Size |
L(mm) |
1650 |
|
|
W(mm) |
850 |
||
|
H(mm) |
1400 |
||
|
Weight (kg) |
320 |
||
Competitive Advantage:
It is convenient to clear die-casting, injecting and others runner model
Easy to use and portable, model can be cleaned without disassembling, convenient mould maintenance
A number of alarm protections to protect the machine stable operation.
There will be no water at function of automatic clean
Mould thermal conductivity stability and easy management after cleaning
