High Efficiency Hot Chamber Die Casting Machine With Control Oil Temperature

High Efficiency Hot Chamber Die Casting Machine With Control Oil Temperature
High Efficiency Hot Chamber Die Casting Machine With Control Oil Temperature High Efficiency Hot Chamber Die Casting Machine With Control Oil Temperature High Efficiency Hot Chamber Die Casting Machine With Control Oil Temperature

Large Image :  High Efficiency Hot Chamber Die Casting Machine With Control Oil Temperature

Product Details:
Place of Origin: Zhejiang China
Brand Name: HAICHEN
Certification: ISO9001:2000, CE
Model Number: HCGH140
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Packaging Details: Wooden Pallet
Delivery Time: 25Days
Payment Terms: 30% as deposit, 70% by T/T before shipment
Supply Ability: 160-220SETS/One Month

High Efficiency Hot Chamber Die Casting Machine With Control Oil Temperature

Description
High Light:

copper Die Casting Machine

,

die casting equipment

HCGH140 Hot Chamber Die Casting Machine





lt scientifically comboin of the high sawing-engry technology and machine performance -the favoured people, the intelligent users.



Competitive advantages:


The system carries out pressure-flow closed-loop control technology,guarantee the high accuracy for repeating positioning of the motions,the servo driver outout matching power will be responsed quickly according to the technical parameter order set by controller. And can control oil temperature effectively, keep top quality of castings and increase machine using period.



Description:



The Die Casting Machine has been designed by electricity integration control and has three work program that are manual, semi-auto and full auto. The clamping unit has been designed toggle structure having dilation force. The machines are used for color metal products such as plumbum, zinc, copper, aluminum and magnesium.



HCGH140 HOT CHAMBER DIE CASTING MACHINE
ITEM UNIT PARAMETER
Clamping Force KN 1400
Clamping Stroke mm 350
Ejecting Force KN 109
Ejecting Stroke mm 80
Die-Thickness(Min.Max) mm 200-500
Space between Tie-Bars mm 430*430
Diameter of Bars mm 80
Injection Position  mm 0,-80
Injection Force KN 109
Injection Stroke mm 170
Spary-Gun Stroke mm 260
Casting Volume Kg 2.2(Zn) 2.6(Zn)
Injection Plunger Diameter mm 60 65
System Working Pressure Mpa 14
Dry.Cycle Time s ≤7
Motor Power  Kw 11
Crucible Capacity Kg 650
Fuel Oil Kg/h 5.5
Electric Furnace Kw 5.7
Tank Capacity L 400
Machine Weight  Kg 6000
Overall Dimensions of Machine(L*W*H) mm 4550*1800*2350
