Spiral Type 10HP Air Cooled Industrial Water Chiller For Machine Cooling
| Place of Origin: | China |
| Brand Name: | TOPSTAR |
| Certification: | CE |
| Model Number: | TCA-10 |
| Minimum Order Quantity: | 1 set |
| Price: | USD5000 |
| Packaging Details: | Plywood case package suitable for ocean shipping |
| Delivery Time: | 20 work days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 200 sets per month |
|
Detail Information |
|||
Product Description
10HP Air Cooled Industrial Water Chiller For Machine Cooling
Features
1. To adopt imported superb compressors and pumps to ensure safe & quiet running , power saving and
durable service life.
2. To employ microcomputer with easy operation which can control temperature within ±3℃ to ±5℃
precisely.
3. Unique design for condenser and heat- dispersion unit result in excellent heat-exchange effect.
4. To equip with electrical current overload protection, high & low-pressure switch, electronic timer delay
safety device. It will alarm to display faulty while any malfunction occurs.
5. To adopt with internal 304 stainless steel insulated water tank with durable service life for easy cleaning
& maintenance.
6. Complete safety devices including power reverse phase & power short phase and anti-freeze
protection.
7. Ultra low temperature type of chillers can reach below -15°C .
8. Chillers for anti-alkaline & anti-acid type can be customized.
TCA Series Air Cooled Chiller
Air Cooled Chillers adopt fin condensers (without need of cooling water) with the features of rapid heat
transmission and excellent heat dispersion. This series can be afforded cooling ranges from 5~35℃,
even lower to 3℃ (temperature controlled accuracy at ±1℃).
The compressors' power range from 3HP~50HP and cooling capacities range from 7800~ 128500 Kcal/hr.
Specification
| Model | TCA-10 |
| Cooling Capacity | 29900W |
| No.of Compressors | 2 sets |
| Compressor Total Power | 10hp |
| Refrigerant | R22 |
| Evaporator Type | Spiral Type |
| Condenser Type | Tube-fin Type |
| No.of Blower | 2 sets |
| No.of Cooling Water inlet/outlet | 1 group |
| Cooling Water Inlet/Outlet Size | DN40 |
| Water Tank Capacity | 130L |
| Pump Power | 1hp |
| Pump Flow | 100L/min |
| Pump Lifts | 16M |
| Power Supply | AC380V/3P/50HZ |
| Dimension | 158x75x150cm |
| Weight | 365kg |
