Dust Free Rockwool Insulation Blanket For Process Temperature Control
| Place of Origin: | China |
| Brand Name: | OEM |
| Minimum Order Quantity: | Full container load |
| Price: | Negotiable |
| Packaging Details: | Shrinkage wrap with PE |
| Delivery Time: | In 10 days after order |
| Payment Terms: | T/T |
| Supply Ability: | 10000 tons |
|
Detail Information |
|||
Product Description
Dust Free stonewool Insulation Blanket For Process Temperature Control
Quick Detail:
Free of dust,non-itch,flexible stonewool product in roll form ideal material for fire proof,
temperature control, energy conservation, condensation prevention and personnel protection,
sound absorption for industrial application.
Description:
stonewool (mineral) products is an economical light weight thermal insulation material which is well recognized as one of the best material for thermal and insulation purpose is manufactured from a mixture of natural rocks (basalt and dolomite) melted at high temperature to form a molten matrix, which is then passed through an air stream that cools the material and forms long fibrous strands. These strands are bonded together to form slabs, blocks, blankets, pipe covers and granulates (non-bonded). The material is chemically and biologically inert and free from plant pathogens.
Applications:
Tungkin dust free stonewool blanket is to process temperature control, energy conservation, condensation prevention and personnel protection for the power generating, metallurgical, oil refining and chemical industries, including plant and equipment such as exhaust flues, hot gas ducts, boilers, heat exchangers, reactors, storage tanks, furnaces, ovens, autoclaves, precipitators, stacks, air-conditioning ductwork, refrigeration equipment and kilns.
It is easily installed by impaling the blankets on weld pins and securing with speed clips. The unfaced surface of the stonewool blanket is to be applied to the hot surface to be insulated.
The Industrial stonewool blanket can be laminated with aluminum foil, fiberglass cloth or stitched with galvanized wire mesh and other facing material upon the request of customers for particular purpose.
Other size can be made upon request.
Facing:
stonewool Blanket can be stitched with galvanized wire mesh and laminated with Aluminum Foil, Black Tissue and other facing material.
Main Technical data
|
Item |
Unit |
Data |
Remarks |
|
Fiber diameter |
μ |
4~7 |
|
|
Shot content |
% |
<5 |
|
|
Service temperature |
ºC |
-269 ~ 850 |
|
|
Combustibility |
|
non-combustible |
DIN 4102 |
|
Moisture absorption |
% |
0.2 |
ASTM C-553-70 |
|
Water repellency |
% |
>98 |
JIS 9512 |
|
Chemical Properties/Biological Properties
|
stonewool is neutral (PH 7) or slightly alkaline and meet the requirement of standard ASTM C 795 JIS A 9504. It will normally not support the growth of molds, fungi and bacteria |
||
Sound absorption property
|
Density |
Thickness |
Absorption Value at various frequency (HZ) |
||||||
|
(Kg/m3) |
(mm) |
100 |
125 |
250 |
500 |
1000 |
2000 |
4000 |
|
80 |
25 |
0.03 |
0.04 |
0.09 |
0.24 |
0.57 |
0.93 |
0.97 |
|
80 |
50 |
0.06 |
0.08 |
0.22 |
0.6 |
0.93 |
0.98 |
0.9 |
|
100 |
50 |
0.09 |
0.13 |
0.33 |
0.61 |
0.83 |
0.89 |
0.95 |
|
120 |
50 |
0.08 |
0.11 |
0.3 |
0.75 |
0.91 |
0.89 |
0.97 |
|
80 |
75 |
0.21 |
0.31 |
0.59 |
0.87 |
0.83 |
0.91 |
0.97 |
|
80 |
100 |
0.27 |
0.35 |
0.64 |
0.89 |
0.9 |
0.96 |
0.98 |
|
80 |
100 |
0.1 |
0.3 |
0.7 |
0.9 |
0.92 |
0.97 |
0.9 |
|
100 |
100 |
0.33 |
0.38 |
0.53 |
0.77 |
0.78 |
0.87 |
0.95 |
|
120 |
100 |
0.3 |
0.38 |
0.62 |
0.82 |
0.81 |
0.91 |
0.96 |
Competitive Advantage:
TUNGKIN stonewool (Mineralwool) has advantages of low thermal conductivity, less shot content,free of dust, non-itch.
Tag:
stonewool BLANKET, stonewool BLANKET WITH WIRE MESH, WIRED MATTRESS, FIBER MESH, MINERAL BLANKET, MINERAL WIRED MESH BLANKET.
