Heat - resistant Epoxy Resin GFRP C Channel Fiber Sheet 200*60*10mm

Product Details:
Place of Origin: Hubei, China
Brand Name: Yulong
Certification: ISO9001,ISO140001
Model Number: YLC-200*60*10
Payment & Shipping Terms:
Minimum Order Quantity: 1*20ft
Packaging Details: Plywood pallet with plastic wrapped for packing
Delivery Time: About 5-10 days after deposit received
Payment Terms: TT,L/C, Western Union, Money Gram
Supply Ability: 16,000Tons/week
Contact Now

Product Description

Heat-resistant Epoxy Resin GFRP C Channel Fiber Sheet 200*60*10




  • Non-Corrosive
  • Lower Life Cycle Cost
  • Easy to Fabricate and Install
  • Lightweight/High Strength
  • High Impact Strength
  • Greater Flexural Strength Than Timber
  • Dimensionally Stable
  • Flame Retardant
  • Electrically Non-Conductive
  • Resists Insect Damage
  • Low Water Absorption
  • Non-Leeching



Pultrusion Technique:


Creels of unidirectional roving provide longitudinal tensile strength or the strength along the length of the profile. Rolls of continuous filament mat, woven roving, or stitched fabric provide the profile with its transverse properties or its strength across the width of the profile. All reinforcements are first fed through preforming guides that will begin to shape the raw glass fibers in to the finished profile. The glass is then pulled into a resin bath that saturates or “wets out” the reinforcements. The resin bath contains a mixture of resin, most commonly polyester or vinylester, pigments to add color, filler to enhance properties, and a catalyst to aid in curing or to turn it from a liquid to a solid.


Fiberglass reinforced plastic is one of the strongest and most durable materials in the world. Pultrusion is a manufacturing process for producing continuous lengths of fiberglass reinforced plastics shapes with a constant cross section. Surfacing veil is added to give the profile a resin rich surface and enhance the appearance of the final product. The wet out reinforcements now enter the heated pultrusion die. The heat begins the thermosetting reaction process that cures the finished profile. The cured profile is now advanced by a caterpillar style puller to the cut off saw where it will be cut to its final length.

Heat - resistant Epoxy Resin GFRP C Channel Fiber Sheet 200*60*10mm


Physical Property:


Product name:

FRP/GRP Pultruded Channel

Product dimension

(Length x Width x thickness—mm)




customized size is available.

Raw Materials:

  • Reinforcement material: Fiberglass, glass mat, continuous strand mat, surfacing mat, needled mat.
  • Basis material: Unsaturated polyester resin, epoxy resin, vinylester resin


Grey, Blue, Yellow, Red, other customized colors


1.5-2.0 g/cm3





  • Electrical & lamp; Electronics markets
  • Cable tray, radome, insulation ladder, etc.
  • Chemical anti-corrosion markets
  • Grating floor, handrail, working platform, underground pressure pipe, stairs, etc.
  • Building construction markets, bridge protection closed system, movable house structure, working platform, window frame, window sash and its components, etc
  • Foundation engineering markets freeway antiglare shield and its handrail, lamp post, water treatment, bracket for huge industry cooling tower, etc


Our other FRP composite products are pultrusion fiberglass square tube, frp channel, frp beams, frp round tube, frp flat bar, frp angle, frp cable tray, frp rod, frp rock bolt, frp rebar, frp mortar pipe and other frp profiles.

Contact us for more details.
