447200 Kcal/h Air Cooled Screw Water Chiller High Efficiency

Send Me The Latest Product Alerts
(No SPAM - We would not sell or share your e-mail address.)

447200 Kcal/h Air Cooled Screw Water Chiller High Efficiency

Good Quality 447200 Kcal/h Air Cooled Screw Water Chiller High Efficiency Sales

Large Image :  447200 Kcal/h Air Cooled Screw Water Chiller High Efficiency

SHENZHEN AODE MACHINERY CO.,LTD

Verified Supplier

China

Business type: Manufacturer, Exporter, Seller

Telephone : 86-0755-33232001-829

No.37,Dayang Industrial Area, Xingang East Road, Lougang Boulevard, Songgang Town, Bao'an District, Shenzhen

Product Details:

Place of Origin: China
Brand Name: Aode
Certification: ISO,CE
Model Number: AC-520AD

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Packaging Details: Protective/air bubble film, Wooden case. As client’s requirement.
Delivery Time: Within 20days after receiving deposit
Payment Terms: 30% T/T in advance, 70% balance before we delivery
Supply Ability: 500pcs/month
Detailed Product Description
Product Name: Air Cooled Screw Chiller Brand Name: AODE
Application: Pringting|Rubber Presses|Extruder Certification: CE|ISO
Compressor Type: Semi-enclosed Screw-type Dimension: 4520*2260*2570mm
Power Supply: 3N-50HZ-380V Temperature Range: 7-35℃
Theory: Air Cooled



447200 Kcal/h Air Cooled Screw Water Chiller High Efficiency





Quick Detail:



1. Temperature controlled7-35℃,precision controlled ±2℃

2. Max. Running current:327.6A

3. Refrigerant charge:67.5×2KG

4. Certification:CE & ISO

5. Compressor type: Semi-enclosed screw-type

6. Refrigerating capacity: 447200Kcal/h

7. Warranty:1 year





Description:





AODE import compressor from Europe, America and Japan (Hanbell Levin Beverly), Throttle components from Danfoss (Denmark) and Alco (US), Electrical devices supplied from OMRON, FUJI, TE, LG, MOELLER, ABB and WEST.

All of our compressors have high and low voltage protection, internal overheating protection. Our chillers have Perfect safety protection, fault display, easy repair and maintenance even without professionals.

Besides, we have Low water flow alarm devices and Low water temperature anti-icing alarm. Refrigerating system welded with oxygen free method, to reduce oxides and ensure the smooth surface. AODE use Stainless steel plate, coil type, shell and tube, finned high efficiency heat exchanger. What’s more, we import micro-computer or PLC and use RS485 communication function to realize automatic management. Most important is we have High-efficiency evaporator and condenser which can save energy by more than 30%. Temperature control range is 7-35℃, Temperature control accuracy is ±2℃.







Specifications:



ITEM

UNIT

AC-520AD

Refrigerating capacity

Kcal/h

447200



KW

520

Power Input

KW

194

Maximum Running Current

A

327.6

Energy adjust range

%

100-75-50-25-0

Power supply



3N-50HZ-380V

R22 Refrigerant

Filling Volume

kg

67.5×2



Control mode



Thermostatic Expansion valve

Compressor

Model



Screw semi-hermetic



Power

Kw

91×2

Condenser



Copper Coil With Aluminium Fine

Fan

Type



Low Noise Aluminium Blade Axial Fa



Air Flow

M3/h

178000

Evaporator

Model



Shell and Tube



Chilled water flow

M3/h

89.4



Water resistance

Kpa

47



Water inlet/outlet diameter

DN

125.0

Protecting equipment



High/Low Pressure switch, Anti-frost Protector, Fusible Plug, Overload Protector, Motor Overheat Protector, Automatic Temperature Sensitive Switch, Anti-phase Protector

Size(L×W×H)

mm

4520×2260×2390

Weight

kg

3850

Running Weight

Kg

4030





Applications:



Aluminium Alloy: Car accessories

Magnesium alloy: Communication device, navigation

Hot Rolling Machine: Calender Rolls, Wood Presses, Laminating Presses,Molding Presses, Rubber Presses, Jacketed Vessels, Reactors, Heat Exchangers, Mixers, Printing Machines, Asphalt, Vulcanizing Presses.
Die casting,plastic  Injection molding, light guide plates, connectors, Chemical engineering, Shoe materials, Pringting and dyeing, Drying and banburying.





Competitive Advantage:



  1. Our core competitiveness:advance technology,the pioneer of TCU industry, Convenient and efficient nationwide service network

  2. Excellent R&D team

  3. Customization thick copper pipe 1.0-1.2

  4. Our core concept:Innovation, high-quality, integrity, service, focus

  5. High density heat insulation cotton and aluminum foil

  6. Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST

  7. The thickness of our machine rack is 1.2mm

  8. We have the production certification organic heat transfer material heater

447200 Kcal/h Air Cooled Screw Water Chiller High Efficiency447200 Kcal/h Air Cooled Screw Water Chiller High Efficiency





Nowadays, Aode Machinery Co.,ltd continue to uphold the purpose of international standards designs and high quality products, applying ourselves to providing high standard products and whole-journey nanny service. Our products are widely applied in plastic injection molding, light guide plates, connectors, chemical engineering, compression casting, reaction kettles, rubber tires, calendaring, shoe materials, printing and dyeing, drying and banburying and tec. And widely sold to Japan, America, Italy, Brazil, Southeast Asia, Africa and etc. The brand recognition from the market is sufficient to prove that our temp. control system can replace the imported similar products. Belows are our honor clients.
