    Hot Water Mold Temperature Controller Unit

    Product Details:

    Place of Origin: China
    Brand Name: Aode
    Certification: ISO,CE
    Model Number: AWM-10A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Packaging Details: Protective/air bubble film, Wooden case. As client’s requirement.
    Delivery Time: Within 20days after receiving deposit
    Payment Terms: 30% T/T in advance, 70% balance before we delivery
    Supply Ability: 500pcs/month
    Get Latest Price Mail Us
    Product Name: Water Temperature Control Unit
    Brand Name: AODE
    Application: Plastic Injection Molding, Pringting
    Certification: CE, ISO
    Cooling Method: Direct Cooling
    Heat Transfer Medium: Water
    Heating Energy: 9KW
    Maximum Power Consumption: 10KW
    Power Supply: AC3∮380V 50HZ 3P+E(5M)
    Temp Control Accuracy: PID±1℃
    Temperature Range: 15℃-120℃
    High Light:

    industrial chiller units

    ,

    Water Temperature Controller

    Product Description



    Hot Water Heater Mold Temperature Controller Unit , Industrial Water Chiller





    Quick Detail:



    1. Temp. Control accuracy: PID±1℃

    2. Range of temperature control:+15℃-120℃ for incoming water

    3. Certification:CE & ISO

    4. Controller:microcomputer

    5. Heating capacity: 9KW

    6. Maximum power consumption: 10KW

    7. Alarm function:Excess temperature, open phase, oil starvation, overloading, reverse turn





    Description:



    • Explosion-proof equipment(optional)
    • Air blowing and return water function(optional)
    • Thermometer for return water
    • Automatic air-exhausting function after startup
    • Switchover of heating power
    • Instant cooling shut-down function(optional)
    • RS485 communication function for automated management(optional)
    • BY-PASS pressure release loop for hot water
    • Customizable multi-point temperature control unit
    • Customizable horsepower and heating power of water pump
    • Brands OMRON, FUJI, TE, LG, MOELLER, ABB, and WEST for electric appliances
    • Range of temperature control: +15℃-180℃ for incoming water
    • Stainless steel integrated pipelines for less pipe resistance and rust
    • Control mode: imported microcomputer or PLC(optional)
    • Perfect safety protection, fault display, easy repair and maintenance even free of professionals





    Specifications:



    ITEM

    UNIT

    AWM-10A

    Temp control range

    Inlet water temperature +15℃-120℃

    Temp control accuracy

    PID±1℃

    Power supply



    AC3∮380V 50HZ 3P+E(5M)

    Heat transfer medium



    Water

    Cooling method



    direct Cooling

    Heating capacity

    KW

    9

    Horsepower of pump

    hp

    1

    Working flow of pump

    L/min

    33

    Working pressure of pump

    Kg/cm2

    2.0

    Max. power consumption

    KW

    10

    Alarm function



    Open phase/water depletion/excess temperature/overloading/reverse turn

    Cooling water pipe

    inch

    1/2

    Circulating water pipe

    inch

    3/8×4

    Size(L×W×H)

    mm

    620×325×645

    Weight

    kg

    72





    Competitive Advantage:



    1. Our core competitiveness:advance technology,the pioneer of TCU industry, Convenient and efficient nationwide service network

    2. Customization thick copper pipe 1.0-1.2

    3. Our core concept:Innovation, high-quality, integrity, service, focus

    4. High density heat insulation cotton and aluminum foil

    5. Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST

    6. The thickness of our machine rack is 1.2mm.

    7. Strict quality control system

    8. We have the production certification organic heat transfer material heater





    Applications:



    Injection industry

    Hot Rolling Machine: Calender Rolls, Wood Presses, Laminating Presses,Molding Presses, Rubber Presses, Jacketed Vessels, Reactors, Heat Exchangers, Mixers, Printing Machines, Asphalt, Vulcanizing Presses.
    Die casting,plastic  Injection molding, light guide plates, connectors, Chemical engineering, Shoe materials, Pringting and dyeing, Drying and banburying.





    Hot Water Mold Temperature Controller Unit 0




    Hot Water Mold Temperature Controller Unit 1



    Hot Water Mold Temperature Controller Unit 2





    Nowadays, Aode Machinery Co.,ltd continue to uphold the purpose of international standards designs and high quality products, applying ourselves to providing high standard products and whole-journey nanny service. Our products are widely applied in plastic injection molding, light guide plates, connectors, chemical engineering, compression casting, reaction kettles, rubber tires, calendaring, shoe materials, printing and dyeing, drying and banburying and tec. And widely sold to Japan, America, Italy, Brazil, Southeast Asia, Africa and etc. The brand recognition from the market is sufficient to prove that our temp. control system can replace the imported similar products. Belows are our honor clients.



    Hot Water Mold Temperature Controller Unit 3
