    Large Square Cooling Tower Equipment

    Product Details:

    Place of Origin: China
    Brand Name: HOHD
    Certification: ISO
    Model Number: CNTS
    Features: energy saving cooling tower
    Applications: industrial cooling tower|Chemical
    Contact method: Wet cooling tower|open cooling tower
    Material: steel cooling tower
    Model: CNTS
    Shape: square cooling tower
    Ventilation: Mechanical draft cooling tower
    Flow direction: counterflow cooling tower

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: According to customer’s requirment
    Delivery Time: 7-15days
    Payment Terms: L/C T/T,Paypal
    Get Latest Price Mail Us
    High Light:

    water cooling tower

    ,

    wet cooling tower'

    Product Description



    Large Square Cooling Tower Equipment





    Quick Detail:



    CNTS serial counter flow cooling tower applies the full steel structure with FRP enclosure casing, which structure not only greatly decrease weight of tower, but also looks beautiful.

    The rigid truss system is used for the tower’s body of FRP cooling tower with steel structure. The connections between all parts are galvanized bolts. The steel pipe with larger turning radius is used as bellied rod to form the truss between beam and column. According to section junctions, the number may be added or reduced. So that it makes the structure of tower’s body not only have better whole rigidity but also the stress distribution have been changed. It is reasonable better for the structure to withstand force. The structure has the function to withstand forces come from all directions, and concentrates load, non-symmetric force and dynamic load caused by earthquake etc. it is very superior to reduce the vibration of cooling tower.





    Specifications:



    Model

    Waterflow per cell

    (m3/h)

    Dimension

    Mechnical equipment

    L(mm)

    W(mm)

    H(mm)

    Fan Dia.

    (mm)

    Airflow(m3/h)

    Motor(KW)

    CNTS-3500

    3500

    15200

    15200

    10800

    8530

    2100000

    132

    Design condition:

    1. The inlet temp. and outlet. Temp. is 43℃ and 33 ℃;
    2. The WBT is 28℃;
    3. SS is less than 50 ppm.





    Description:



    CNTS serial square counter flow cooling tower with steel structure is a advanced kind of cooling tower with perfect technology and reliable performance. The cooling tower has passed the inspection and test for the running tower and all kind of performance data have hit or exceed the national standard value stipulated in GB7190-2008 “Cooling tower of Plastic with enhanced glass fiber”.





    Applications:



    CNTS serial cooling tower with ascendant performance and good quality have been widely used in the circulating water system in such fields as Air-conditioning, Electric, Chemical, Metallurgy.





    Competitive Advantage:



    • Non-metalizing of the components
    • Streamlining of air-flow field
    • Low energy-consumption of operation
    • Super low loss of drift
    • High-qualified draught device
